Tab Break not displaying in DocType Builder on Frappe Cloud despite correct field layout

ERPNext
1

Hi everyone,

I’m working on Frappe Cloud, so I don’t have terminal/bench access and cannot run commands like bench migrate, bench clear-cache, or edit the DocType JSON manually.

I’m facing an issue where the second Tab Break is never displayed in a custom DocType.

Environment

  • Platform: Frappe Cloud

  • Using: DocType Builder

  • No terminal/bench access

    Details (Tab Break)
    Product Details (Section Break)
    Product Name (Data)
    Product Type (Select)
    Generic Name (Data)
    …
    Product Knowledge (Section Break)
    Product Description (Long Text)

    TEM (Tab Break)
    TEM (Section Break)
    Type (Select)
    Column Break
    Image Option 1 (Attach Image)
    Follow up (Section Break)
    Long Text

    Problem

    When I click New to create a document, only the first section is shown.

    The TEM tab never appears.

    Things I’ve already tried

    • Added a Tab Break at the beginning (Details)

    • Deleted and recreated the TEM Tab Break

    • Removed and recreated the Section Break after TEM

    • Saved and reloaded multiple times

    • Hard refresh

    • Opened a new document after saving

    • Verified the Tab Break isn’t hidden

    • Cleared all “Display Depends On”, “Mandatory Depends On”, and “Read Only Depends On” properties

    • Rearranged the field order multiple times

    The field layout looks correct in the DocType Builder, but the second tab is never rendered in the form.

    Since this is Frappe Cloud, I cannot use bench commands or modify files directly.

    Has anyone experienced this on Frappe Cloud or knows if this is a DocType Builder bug or a missing step?

    Any help would be greatly appreciated.

2 Likes
2

Hi @Dhruv090123 and welcome to the community

Have you tried Ctrl + Alt + R

Also press F12 and go to console and explore the JS API - maybe you can get a hint from there on what is not loading (error messages)
(e.g. frappe.boot.sitename)

Also try the cur_frm object: -
cur_frm.meta.fields.forEach(df => {console.log(df.fieldtype, df.label, df.fieldname); });

Hope it helps
