How We Successfully Integrated ZKTeco with ERPNext using zkteco_checkins_sync

ERPNext
, , , ,
1

Hello everyone!

As many of you know, integrating biometric attendance devices with ERPNext requires a reliable bridge between the hardware and the ERP system. ERPNext itself recommends ZKTeco devices for this purpose, and after some trial and error, we’ve successfully set up a full end-to-end integration. Here’s how we did it.

The Integration Flow

ZKTeco Device → ZKBio Time Software → zkteco_checkins_sync (Frappe App) → ERPNext

How It Works

The app zkteco_checkins_sync acts as a bridge between ZKteco and ERPNext. It pulls attendance punch-in/punch-out data from the ZKteco API and automatically creates Employee Checkin records in ERPNext. Think of it as the missing link that connects your biometric hardware to your HR module.

Step-by-Step Process

Step 1 — Set up your ZKTeco device. Make sure your ZKTeco biometric device is physically set up, enrolled with employee fingerprints/face data, and connected to your local network.

Step 2 — Connect it to ZKBio Time software. Install ZKteco on your server, add your device to it, and confirm that punch transactions are appearing in the software. Note down your Server IP and Port (usually port 80) — you’ll need these later.

Step 3 — Install zkteco_checkins_sync on your Frappe/ERPNext instance

bench get-app GitHub - DeliveryDevs-ERP/Zkteco-Checkins-Sync · GitHub

bench --site your-site.com install-app zkteco_checkins_sync

bench migrate

Or install it directly via the Frappe Cloud Marketplace if you’re on Frappe Cloud.

Step 4 — Configure the app. Go to Setup → ZKTeco Checkin Sync → ZKTeco Config in ERPNext and fill in:

  • Server IP and Port of your ZKBio Time server

  • ZKTeco Time superuser username and password

  • Click “Register API Token”

  • Click “Test Connection” to verify everything is working

Step 5 — Map your employees. The app matches ZKTeco’s emp_code to ERPNext’s Employee ID field. Make sure they match exactly — including leading zeros (e.g., 001 must be 001 on both sides).

Step 6 — Enable Sync and set your frequency. Enable sync and choose how often the app should pull data — anywhere from every 10 seconds to once an hour, depending on your office size.

Once this is done, attendance data flows automatically from your ZKTeco device all the way into ERPNext Employee Checkin records.

Let’s Help Each Other

If you’re attempting this integration, do give it a try! Drop your questions or issues in the comments below — we’ve been through the process and would be happy to help you troubleshoot. The community grows stronger when we share what we learn. :raising_hands:

ERPNext Implementers| Frappe Partner| Satat Technologies

1 Like
2

@Falguni_Satat_Tech

Thanks for this guide.

I have seen on Telegram and Forums a couple of people asking which devices do they need to buy to implement this as it seems ZKTeco are trying to force people to use their software/cloud services i.e. restrcitng their API from 3rd party vendors

Would you be able to provide such a list?

3

@asieftejani Glad to hear the guide may have helped you. For the list you’re looking for, please check the link below. It should answer your questions.

Thanks in advance, and feel free to share your comments if there’s anything more, we can help you with. GitHub - fananimi/pyzk: Unofficial library of zkteco fingerprint attendance machine · GitHub

4

Thanks for the reply. I did see the list some time back and was hoping for a more updated one as some models seem to be very old. Let me know if you come accross an updated version

5

@asieftejani Oh okay! We implemented it using the ZKTeco MiniAC. You can try this; it might help you
