Installation tutorial

frappe installation tutorial , for
Ubuntu 22.04
frappe bench 5.24.1
frappe framework v15.66.1

update system

sudo apt update
sudo apt upgrade -y

install system dependencies

sudo apt install -y \
  git \
  python3.10 \
  python3.10-dev \
  python3.10-venv \
  python3-pip \
  pkg-config \
  software-properties-common \
  libfontconfig1 \
  xvfb

install redis

sudo apt install redis-server
# do not start the redis server the bench script will start it on its own

install mariadb

sudo apt-key adv --fetch-keys 'https://mariadb.org/mariadb_release_signing_key.asc'
sudo add-apt-repository 'deb [arch=amd64] http://mirror.mariadb.org/repo/10.6/ubuntu jammy main'
sudo apt update
sudo apt install -y mariadb-server-10.6 mariadb-client-10.6 libmariadb-dev
sudo systemctl start mariadb
sudo systemctl enable mariadb
sudo mysql_secure_installation
sudo cp /etc/mysql/mariadb.conf.d/50-server.cnf /etc/mysql/mariadb.conf.d/50-server.cnf.bak
sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf

[server]
user = mysql
pid-file = /run/mysqld/mysqld.pid
socket = /run/mysqld/mysqld.sock
basedir = /usr
datadir = /var/lib/mysql
tmpdir = /tmp
lc-messages-dir = /usr/share/mysql
bind-address = 127.0.0.1
query_cache_size = 16M
log_error = /var/log/mysql/error.log

[mysqld]
innodb-file-format=barracuda
innodb-file-per-table=1
innodb-large-prefix=1
character-set-client-handshake = FALSE
character-set-server = utf8mb4
collation-server = utf8mb4_unicode_ci

[mysql]
default-character-set = utf8mb4

sudo systemctl restart mariadb

install the pdf thing

wget http://archive.ubuntu.com/ubuntu/pool/main/o/openssl/libssl1.1_1.1.1f-1ubuntu2_amd64.deb
sudo dpkg -i libssl1.1_1.1.1f-1ubuntu2_amd64.deb
wget https://github.com/wkhtmltopdf/packaging/releases/download/0.12.6-1/wkhtmltox_0.12.6-1.focal_amd64.deb
sudo apt install -y ./wkhtmltox_0.12.6-1.focal_amd64.deb
wkhtmltopdf --version

install nvm

curl -o- https://raw.githubusercontent.com/nvm-sh/nvm/v0.39.3/install.sh | bash

export NVM_DIR="$HOME/.nvm"
[ -s "$NVM_DIR/nvm.sh" ] && \. "$NVM_DIR/nvm.sh"

nvm install 18.15.0
npm install -g yarn@1.22.19

install frappe

python3 -m pip install --upgrade pip==25.0.1
pip3 install frappe-bench==5.24.1
echo 'export PATH="$HOME/.local/bin:$PATH"' >> ~/.bashrc
source ~/.bashrc

bench init frappe-bench --frappe-branch v15.66.1

create bench

bench new-app appname
bench new-site sub.domain.com
# make it exactly the same as your domain , do not use anything else (setup for a seperate name is different )
bench use sub.domain.com
bench --site sub.domain.com install-app appname

hear your bench start should start working , and all the other bench related commands

but for a production setup you need something that can run in the background
hence the below production setup , once you configure that bench start should stop working and bench restart should work

production

sudo apt -y install supervisor
sudo bench setup production <user name for linux>

sudo apt-get install supervisor
bench setup supervisor
sudo ln -s `pwd`/config/supervisor.conf /etc/supervisor/conf.d/frappe-bench.conf
sudo supervisorctl reread
sudo supervisorctl update
sudo supervisorctl status
sudo nano /etc/supervisor/supervisord.conf

[unix_http_server]
file=/var/tmp/supervisord.sock
chmod=0700
chown=<user name for linux>:<user name for linux>

faced multiple problems with supervisor and nginx so uninstall script for nginx and supervisor

sudo systemctl stop supervisor
sudo apt-get purge supervisor
sudo rm -rf /etc/supervisor

sudo systemctl stop nginx
sudo apt-get purge nginx nginx-common nginx-full
sudo rm -rf /etc/nginx
sudo rm -rf /var/log/nginx
sudo rm -rf /var/www/html
sudo apt-get autoremove
sudo apt-get clean

also delete script for deleting database when faced problems with app

sudo mysql -u root -p
SHOW DATABASES;
DROP DATABASE _fb4b895ec24305ae;

nginx config


upstream frappe-bench-frappe {
        server 127.0.0.1:8000 fail_timeout=0;
}

upstream frappe-bench-socketio-server {
        server 127.0.0.1:9000 fail_timeout=0;
}


server {
    listen 80;
    listen [::]:80;
    server_name
                erpnext.gseven.in
                ;
     return 301 https://$host$request_uri;

}
server {
    listen 443 ssl;
    listen [::]:443 ssl;


        server_name
                erpnext.gseven.in
                ;

		ssl_certificate /etc/ssl/wildcardssl/fullchain.pem;
        ssl_certificate_key /etc/ssl/wildcardssl/privkey.pem;
        root /home/i2k2-admin/frappe-bench/sites;



        proxy_buffer_size 128k;
        proxy_buffers 4 256k;
        proxy_busy_buffers_size 256k;


        add_header X-Frame-Options "SAMEORIGIN";
        add_header Strict-Transport-Security "max-age=63072000; includeSubDomains; preload";
        add_header X-Content-Type-Options nosniff;
        add_header X-XSS-Protection "1; mode=block";
        add_header Referrer-Policy "same-origin, strict-origin-when-cross-origin";

        location /assets {
                try_files $uri =404;
                add_header Cache-Control "max-age=31536000";
        }

        location ~ ^/protected/(.*) {
                internal;
                try_files /erpnext.gseven.in/$1 =404;
        }

        location /socket.io {
                proxy_http_version 1.1;
                proxy_set_header Upgrade $http_upgrade;
                proxy_set_header Connection "upgrade";
                proxy_set_header X-Frappe-Site-Name erpnext.gseven.in;
                proxy_set_header Origin $scheme://$http_host;
                proxy_set_header Host $host;

                proxy_pass http://frappe-bench-socketio-server;
        }

        location / {

                rewrite ^(.+)/$ $1 permanent;
                rewrite ^(.+)/index\.html$ $1 permanent;
                rewrite ^(.+)\.html$ $1 permanent;

                location ~* ^/files/.*.(htm|html|svg|xml) {
                        add_header Content-disposition "attachment";
                        try_files /erpnext.gseven.in/public/$uri @webserver;
                }

                try_files /erpnext.gseven.in/public/$uri @webserver;
        }

        location @webserver {
                proxy_http_version 1.1;
                proxy_set_header X-Forwarded-For $remote_addr;
                proxy_set_header X-Forwarded-Proto $scheme;
                proxy_set_header X-Frappe-Site-Name erpnext.gseven.in;
                proxy_set_header Host $host;
                proxy_set_header X-Use-X-Accel-Redirect True;
                proxy_read_timeout 120;
                proxy_redirect off;

                proxy_pass  http://frappe-bench-frappe;
        }
        # error pages
        error_page 502 /502.html;
        location /502.html {
                root /home/i2k2-admin/.local/lib/python3.10/site-packages/bench/config/templates;
                internal;
        }

        #access_log  /var/log/nginx/access.log main;
        #error_log  /var/log/nginx/error.log;

        # optimizations
        sendfile on;
        keepalive_timeout 15;
        client_max_body_size 50m;
        client_body_buffer_size 16K;
        client_header_buffer_size 1k;

        # enable gzip compresion
        # based on https://mattstauffer.co/blog/enabling-gzip-on-nginx-servers-including-laravel-forge
        gzip on;
        gzip_http_version 1.1;
        gzip_comp_level 5;
        gzip_min_length 256;
        gzip_proxied any;
        gzip_vary on;
        gzip_types
                application/atom+xml
                application/javascript
                application/json
                application/rss+xml
                application/vnd.ms-fontobject
                application/x-font-ttf
                application/font-woff
                application/x-web-app-manifest+json
                application/xhtml+xml
                application/xml
                font/opentype
                image/svg+xml
                image/x-icon
                text/css
                text/plain
                text/x-component
                ;
                # text/html is always compressed by HttpGzipModule
}
